Taglus Autoform Roll
-
Introducing the world’s smallest automated thermoforming roll machine: The Taglus Autoform Roll Machine. This revolutionary device is designed to transform the production of dental aligners. Despite its compact size, it packs a powerful punch with its impressive production capacity, capable of creating 120 aligners per hour.
Specification
Productions Capacity (per hour) 120 Nos. Forming film Roll diameter 500 mm Forming film thickness (max.) 1.5 mm Forming film Width (max.) 101 mm Forming area (max.) 100 x 85 mm Forming height above film line (max.) 30 mm Forming pressure (max.) 5-6 bar Heating power 1 KW Forming tables driven by Pneumatic Drive Total installed power 1.5 kW Air consumption 70 Ltr./ Cycle Power supply 220 V (1- Phase) 50 Hz Estimated Machine weight ~300 Kg
THE TAGLUS AUTOFORM ROLL INTEGRATES ALL ESSENTIAL OPERATIONS INTO A SEAMLESS WORKFLOW:
-
-
Streamlined Production Process:
Infeed Carousel for 3D Models: Efficiently feeds the 3D models into the system.
Automatic Film Placement: Precisely places the film roll for optimal thermoforming.
Forming Station: Ensures perfect thermoforming of the aligners with advanced technology.
Ejection Station: Smoothly transitions thermoformed aligners for further processing. -
Efficiency and Precision :
From film roll to finished product, the Taglus Autoform Roll handles every step with precision, significantly reducing manual intervention and increasing overall efficiency. This compact yet powerful machine is set to transform your production line, delivering high-quality aligners with unmatched speed and consistency.
-
Size
Dimensions of Taglus Autoform Roll Thermoforming Machine (mm): 1620 H X 860 L X 710 W
